    Howo Euro 4 380hp 8x4 Dump Truck with ZF8118 Steering System and 50 Ton Capacity

    Ask Lasest Price
    Brand Name : SINOTRUK HOWO
    Price : $25,400.00/units 1-1 units
    • Product Details
    • Company Profile

    Howo Euro 4 380hp 8x4 Dump Truck with ZF8118 Steering System and 50 Ton Capacity

    Howo Euro 4 380hp 8x4 Dump Truck with ZF8118 Steering System and 50 Ton Capacity
    Howo Euro 4 380hp 8x4 Dump Truck with ZF8118 Steering System and 50 Ton Capacity
    Howo Euro 4 380hp 8x4 Dump Truck with ZF8118 Steering System and 50 Ton Capacity
    Howo Euro 4 380hp 8x4 Dump Truck with ZF8118 Steering System and 50 Ton Capacity
    Howo Euro 4 380hp 8x4 Dump Truck with ZF8118 Steering System and 50 Ton Capacity

    Description:
    SINOTRUCK SINOTRUK Euro 4 380HP 8x4 SINOTRUK HOWO Dump Truck Philippines

    Which is the most famous brand of heavy duty truck in China. It's also the biggest exported quantity of China brand trucks in all over the world. Abundant truck products can meets customers demands very well.

    This type truck is the famous brand of CNHTC group in abroad marketing. it also have a large exporting quantity in recently years, and make a big effort for local infrastructure construction.This type truck need more wide road for the lenght of the whole truck is longer than 6X4 and 4X2 type truck. full expression of heavy duty truck concept. Delicate design, excellent technology, which have the advantages of Comfort, safety, reliability, electronic level geared to international level. Low fuel consumption.

    It is super art in domestic and abroad auto field, full expression of heavy duty truck concept. Delicate design, excellent technology, which will dazzle you as groundbreaking works

    Be comprehensive with Euro2 and Euro3 engine equipped.

    Driving type: 4×2, 4×4 6×2, 6×6 ,6×4, 8×4 etc.

    Power range: 266PS - 420PS.howo Leader In Heavy Duty Truck Industry Driving King On The Road

    High Level Comfortable:Cabin 4 point full -floating air suspension ,adjustable steering wheel with various heightsand angles.air suspension seat, Cruise Constant Speed System,MINI Player .electrical control glass and mirror,ATM Gearbox bunk with AC.

    Top configuration: Diesel brakes +EVB,ABS+ASR+EBL+TPM,More Powerful electronic management system.
    Product Name
    SINOTRUK HOWO 8X4 Dumper Truck
    Chassis Model
    ZZ3317N3867D1
    Driving Type
    LHD (RHD is optional)
    Cabin
    HW76, with one sleeper and two seats, double arm windscreen wiper system with three speeds, damped adjustable driver's seat, with heating and ventilating system, exterior sun visor, safety belts, adjustable steering wheel, air horn, air conditioner, with transverse stabilizer, with four piont support floating suspension+shock absorber.
    Engine
    Make: SINOTRUK
    Diesel 4-stroke direct injection diesel engine
    Engine model: D10.38-40, Euro 4, 380 HP
    6-cylinder in-line with water cooling, turbo-charging and intercooling
    Displacement: 9.726 L
    Transmission
    HW19710, 10F & 2R, with PTO
    Ratio:14.28, 10.62, 7.87, 5.88, 4.38, 3.27, 2.43, 1.80, 1.34, 1.00, 13.91(R1), 3.18(R2)
    Steering
    ZF power steering, modol ZF8118, hydraulic steering with power assitance
    Front Axle
    HF9,1x9000 KGS
    Steering with doubleT-cross section beam
    Rear Axle
    HC16, 2x16000 KGS
    Pressed axle housing, central single reduction with hub reduction,with differential locks between wheels and axles.
    Ratio:5.73
    Propeller Shaft
    Double universal joint propeller shaft with gear-shaped coupling flange
    Chassis
    Frame: Uprofile parallel ladder frame with section of 300x80x8mm,reinforced subframe all cold riveted cross members
    Front suspension:10 semi elliptic leaf spring, hydraulic telescopic double-action shock absorbers and stabilizer
    Rear suspension:12 leaf semi elliptic springs, bogie spring and stabilizer
    Brake
    Service brake: dual circuit compressed air brake
    Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels
    Auxiliary brake: engine exhaust brake
    Electrics
    Operating voltage: 24 V, negative grounded
    Starter: 24 V, 5.4 Kw
    Alternator: 3-phase, 28 V, 1500 W
    Batteries: 2 x 12 V, 165 Ah
    Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light
    Tyres
    12.00R20, radial tyres with one spare tyre
    Fuel Tank
    300L
    Cargo Body
    7800*2300*1500 mm, 27 CBM, Floor 8mm Side 6mm
    Overall Dimension
    11400*2550*3450mm
    Relation Products

    Howo Euro 4 380hp 8x4 Dump Truck with ZF8118 Steering System and 50 Ton Capacity
    Howo Euro 4 380hp 8x4 Dump Truck with ZF8118 Steering System and 50 Ton Capacity

    Competitive Advantage:

    1.Based on strong technical support and top level technology make the trucks with high quality and more reliable

    2.Strong enough engine

    3.With all kinds of truck model, which can full fill your requirements

    4.The key parts adopt the world's top technology products

    5.Usually choose the standard cargo body structure

    6.Using the good quality steel plate, make it has a long service life

    7.The optimized hydraulic control system helps to avoid wrong operation, it has higher safety and running efficiency.

    8.Excellent appearance of cabin, safety, reliable

    9.Competitive price, cost-effective

    10.Quick and efficient spare parts supply bring you more convenient

    11.Fast delivery time, we can arrange production according to your needs exactly and quickly

    12.Professional import and export dealing procedure, make customs clearance more high efficiency

    13.Low fuel consumption
